- Description
-
Details
- The fischer injection mortar FIS EM Plus 585 S is a high-quality epoxy resin mortar for maximum load-bearing capacity in cracked and non-cracked concrete as well as in steel fibre reinforced concrete
- Alongside the injection mortar, the injection system consists of reinforcement steel, the approved components anchor rod FIS A and internal threaded anchor RG M I
- The anchor rod FIS A can be set with variable anchorage depths
- This enables the system to be ideally adjusted to the load to be supported
- This optimises the use of materials
- The epoxy resin mortar is suitable for fixings in indoor and outdoor areas such as shear connectors for concrete layers, or heavy-duty steel constructions
- The approval of the injection mortar for use in glued laminated or glued solid timber of spruce (Picea abies), fir (Abies alba) or pine (Pinus sylvestris) allows the realisation of high-performance and appealing wood-wood, wood-concrete and wood-steel connections
- The ETA assessment guarantees a service life of 100 years
- The expert report of IEA Stuttgart even confirms a working life up to 120 years and thus underlines the reliability and durability of the FIS EM Plus
- The optimised formulation of the epoxy resin mortar FIS EM Plus leads to improved load values in cracked and non-cracked concrete
- The mortar can be used for rebar connections from diameter 8 to 40, including seismic applications
- With the threaded rod FIS A, the loads to be applied can be designed variably by selecting the anchorage depth
- The mortar is approved for diamond drilled and water-filled drillholes as well as seismic applications and thus offers safety under extreme conditions
- For practical use on the building site, FIS EM Plus can be processed at low temperatures down to -5°C.
- Features
Features
DIBt-approval ETA-approval Language on label EL, EN, ES, PT Contents 1 x Cartridge 585 ml 2 x Static mixer FIS UMR Packaging Cartridge Amount 1 pcs GTIN (EAN-Code) 4048962312164 Applications Post-installed rebar connections Jointers for concrete layers Rim beam anchorings Seismic applications Anchorings in diamond-drilled or in waterfilled drill holes Heavy steel constructions Silo installations Tall shelving Sound barriers Temporary or removable fixings (with internal threaded anchor RG M I) Anchorings in sealing surfaces according to WRL (Water Ressources Law) Glued anchorages in wood, see approval for gluing in wood Building materials Approved for anchorings in: Concrete C20/25 to C50/60, cracked and non-cracked Steel-fibre reinforced concrete with max. fibre content of 80 kg/m³ Glued laminated or glued solid timber of spruce (Picea abies), fir (Abies alba) or pine (Pinus sylvestris) Also suitable for: Natural stone with dense structure You can find detailed information on building materials in the registration document. Approvals ETA-23/0842 ETA-19/0657 ETA-22/0001 ETA-17/1056 ETA-17/0979 DoP No. 0341 DoP No. 0367 DoP No. 0366 ESR-1990 Z-74.8-199 Z-74.8-211 Z-9.1-914 Report No MRF 19 26082687/C EPD-DBC-FIW-20230530-CBA1-EN
