- Description
-
Details
- The hammer-in plug with plastic nail and mushroom head for simple, fast and economic installation
- The fischer Hammerfix N-P K with mushroom head consists of a plug and a nail screw made of high-quality nylon
- These are already pre-fitted for quick assembly
- The Hammerfix is led through the component in the time-saving through-type installation
- When driving in the nail screw, the fixing sleeve expands and anchors itself securely in the building material
- The N-P K is ideal for fixing of thin components and in the viewing area
- The N-P K is completely made of plastic, conducts no electricity and thus is ideal for electrical installations
Top Features
- Fast Hammerset installation saves time: ideal for series installation
- Simple and secure installation: Integrated hammer-in stop prevents premature anchor spreading
- Subsequent dismantling of the nail screw with a cross-slot recess is possible
- With mushroom head.
Advantages
- Time and money savings thanks to fast hammerset installation
- This enables cost-effective series installations
- Easy installation thanks to integrated hammer-in stop
- This avoids the premature expansion of the plug
- Increased flexibility due to subsequent dismounting
- The thread of the nail screw in conjunction with the cross-slot recess allows the screw to be screwed out
- Diverse usage possibilities thanks to the large assortment in different diameters and usable lengths.
- Features
Features
Drill diameter (d0) 6 mm Effect. anchorage depth (hef) 30 mm Anchor length (l) 40 mm Min. drill hole depth for through fixings (h2) 55 mm Max. fixture thickness (tfix) 7 mm Packaging Folding box Amount 50 pcs GTIN (EAN-Code) 4006209503423 Applications Foils Metal sheets Signs Installations in the visible area Building materials Concrete Solid sand-lime brick Brick Natural stone Solid block made of lightweight concrete Aerated concrete Solid plasterboard
