This floor standing drill has adjustable tilting table and rise and fall height adjustment by rack and pinion.
All models are fully CE certificated and approved for use in educational establishments and the industrial workplace.- Features
Features
Base Size:
460 x 275mm Collar Diameter: Ø60mm Column Diameter: Ø80mm Drilling Capacity (Chuck Size): 16mm Maximum Distance Spindle to Base: 1230mm Maximum Distance Spindle to Table: 800mm Motor Power (Start): 450W(650W) Nett Weight: 58.7kg Number of Speeds: 16 Optional Accessories: GDMX/KC - Keyless Pillar Drill Chuck 16mm Overall Height: 1630mm Speed Range: 120-3000rpm Spindle Centre to Column: 178mm Spindle Nose Taper: MT2 Spindle Travel: 80mm Supply: 230V Swing: 356mm Working Base Surface Size: 200 x 220mm Working Table Surface Size: Ø310mm
