- Description
-
Details
- Ideal for ambitious modellers and do-it-yourselfers
- Flywheels made of die-cast aluminum with special coating
- Aluminium cast iron worktable swiveling up to 45°
- Equipped with precise 3-rolls saw band guide above and below the table
- Aluminum longitudinal stop with quick clamping precisely adjustable with the aid of a magnifying glass and millimeter scale (except HBS 231-1)
- Two belt speeds adjustable (except HBS 231-1)
- Features
Features
Cutting ranges Max. cutting height 90° 225 mm Max. cutting height 45° 145 mm Max. cutting width with stop 255 mm Max. cutting width without stop 340 mm Dimensions and weights Length approx. 870 mm Width/depth approx. 690 mm Height approx. 1715 mm Weight approx. 76 kg Electrical Data Delivery power 0.8 kW Supply voltage 230 V Mains frequency 50 Hz Extraction port Extraction port diameter 100 mm Saw band Speed(s) 370/800 m/min Length 2560 mm Width 12.7 mm Strength 0,5 mm Work top(s) Length 545 mm Width 515 mm Height 1020 mm Pivot 0 – 45 °
