Fischer 24648 Double Connector Plate DPP 60 - 105mm Pack x 50

• The fischer double connector plates DPP and DPF are suitable for the easy parallel installation of two pipelines
• Thanks to the fixing element, two parallel pipelines can be secured with just a single fixing point
• This cost-effective fixing solution saves time
• Variable distances between the parallel pipelines can be created with the DPF
• The rounded design of the connector plate is ideal for a visual installation
• The galvanized zinc version is suitable for installation in buildings

Advantages/benefits

• The double connector plate design saves a fastening point for the fastening of two pipelines
• The two-part double connector plate DPF is suitable for variable pipe spacing
• The base plate's long slots allow the double connector plate to be easily aligned
• The rounded design of the connector plate is ideal for a visual installatio

Properties

• Material DPP: DC04 (material no. 1.0338) acc. to DIN EN 10130
• Material DPF: DC01 (material no. 1.0330) acc. to DIN EN 10130
• Zinc plating: electro zinc-plated, min. 5 µm

Load Table for Downloading

https://content.fischer.de/cbfiles/fischer/lastentabelle/lt_01_samo-dp-dpf-n_f_%23sen_%23aip_%23v1.pdf

Declaration of Performance for Downloading

https://content.fischer.de/cbfiles/fischer/zulassungen/zd_dop_samontec_f_%23sen_%23aip_%23v1.pdf
