Fischer 566674 Hollow-Ceiling Anchor FHY M12 R Stainless Steel Pack x 25

• The fischer hollow-ceiling anchor FHY is an internal threaded anchor made of A4 stainless steel
• The FHY is set into the drill hole by hand via the pre-positioned installation, and then driven in with the hammer until it is surface-flush with the building material
• When applying the torque, the cone is pulled into the expansion sleeve
• This expands in the cavity and in solid building materials it expands against the drill hole wall
• The fischer hollow-ceiling anchor FHY is ideal for fixing pipelines, cable trays, and air lines in pre-stressed concrete hollow ceilings in indoor areas

Advantages

• The active principle of the anchor means that the FHY can be used in cavities or in solid materials up to 5 cm from the tensioning wire
• This ensures the highest flexibility and user-friendly installation
• The embossed edge prevents the anchor sleeve from slipping in the cavity, thus allowing for trouble-free installation
• The optimised geometry minimises setting energy and allows for use in extremely narrow spaces
• This allows for user-friendly installation
• The metric internal thread means that it is possible to use standard screws or threaded rods for the ideal adaptation to suit the intended use
• External report for the usage of the FHY in seismic conditions

Top Features

• Extremely flexible and installation-friendly: The anchor expands in the cavity and in solid building materials and can be used as close as 5 cm to the tensioning wire
• Full range for indoor and outdoor fixings
• ETA approval for multiple fixing for even more safety
• Fire approval applies from 25 mm thickness of the slap web for even more versatile applications
• Quick and easy installation without special tools
