Fischer 50566 Internal Threaded Anchor RG 16 x 90 M 10 I A4 Stainless Steel Pack x 10

• The internal threaded anchor RG M I is made of stainless steel
• The internal threaded anchor is a systems accessory for various fischer mortar cartridges or injection mortars
• Application with pre-portioned mortar cartridges is especially cost-effective for individual fixings
• During mounting with the resin capsule, set the RG M I through rotating and hitting motions with a hammer drill
• The capsule is destroyed during the setting process, which mixes and activates the mortar compound
• During mounting with injection mortars, the internal threaded anchor is pushed into the drill hole manually by lightly rotating it
• The various mortars bond the entire surface of the RG M I with the drill hole wall
• The internal threaded anchor can be removed when surface-flush and is, for example, mainly suitable for temporary fixings such as for machines in external areas

Top Features

• Surface flush removal enables fixing point to be reused
• Conventional screws and threaded rods can be used
• This lowers costs and complexity
• ETA approval for maximum safety
• Made of stainless steel for fixings used outside
• Suitable for anchorage in cracked and non-cracked concrete in combination with various mortar cartridges or injection mortars

Advantages

• The internal threaded anchor RG MI is suitable for use with resin capsules or injection mortars in concrete
• The internal threaded anchor RG MI allows for the surface-flush removal and reuse of the fixing point
• It therefore offers great flexibility
• The metric internal thread allows for the use of standard metric screws or threaded rods, which enables ideal adaptation in line with the intended use
• Please refer to the approvals of the resin capsules and injection mortar used

Functionality

• For use in conjunction with resin capsules
• The internal threaded anchor RG M I is set using a hammer drill and the accompanying setting tool in rotating and hitting motions
• During setting, the oblique edge of the internal threaded anchor destroys the capsule, and mixes and activates the mortar
• For use in conjunction with injection mortars
• The RG M I is set manually by lightly rotating it until it reaches the drill hole base
• The mortar bonds the entire surface of the internal threaded anchor with the drill hole wall and seals the drill hole.
