Fischer 50347 10 x 135 mm N-S Hammer Fix Nail Screw with Plug - Zinc - Plated Steel Pack x 50
Description / Fischer 50347
The Hammer-in Plug For A Simple Fast And Economical Installation
- The rapid hammerset installation reduces the amount of time required and allows for an economic series installation
- The integrated hammer-in stop prevents the plug from expanding prematurely (jamming), thus enabling a problem-free installation
- Together with the cross-slot recess, the thread of the nail screw allows the screw to be removed, thus allowing for subsequent dismantling
- The wide range of diameters, usage lengths and head shapes provides the correct plug for every fixing
- When hammered in,the nail screw causes the plug to expand in two directions, thus providing a secure anchoring in the building material
- Suitable for push-through installation
For Building Materials
- Concrete
- Solid sand-lime brick
- Building brick
- Natural stone
- Solid brick made from lightweight concrete
- Aerated concrete
- Solid panel made from gypsum
- Vertically perforated brick
- Hollow blocks made from lightweight concrete
Features / Specification
| Drill hole diameter d0 10 [mm] |
|---|
| Effect. anchorage depth hef 50 [mm] |
| Anchor length l 230 [mm] |
| Min. drill hole depth for through fixings h2 245 [mm] |
| Max. fixture thickness t fix 180 [mm] |
| Drive PZ3 |
